MACTURN250
- MACTURN250
- MACTURN350
- MACTURN550
Description
| SPECIFCATIONS |
Model |
MACTURN250 |
MACTURN350 |
MACTURN550 |
| Max turning dia |
∅ mm |
550 |
720 |
| Max work length |
mm |
1,025 |
1,625 |
2,000/3,000 |
| Spindle speed |
min x-1 |
5,000 |
3,500 |
| Turret |
|
U:H1 ATC+L:V12 |
| Motor (VAC) |
kW |
22/15 |
30/25 |
| Floor space |
mm |
3,770×2,645 |
4,560×2,964 |
6,150/7,150×3,073 |
| Spec |
|
W |
| End |
